| Name | Biological Microscope, Binocular Head |
| Code | scitek-0947 |
| Type | Standard |
| Brand | Scitek |
| Category | Microscopes |
| subcategory | Biological Microscope |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Viewing Head : Siedentopf Binocular Viewing Head at 30° IncIined Interpupillary (55-75mm) / Sliding Binocular Head lnclined at 45° Interpupillary (55-75mm)
Eyepiece : Wide Field Eyepiece WF10x18mm
Objective : Achromatic Objective 4x, 10x, 40x, 100x
Retaining optical quality and features, this biological microscope's sturdy design and substantial footprint mark a transition into routine work without compromise.
Biological Microscope Specifications:
| Model | MSC-BH208B | MSC-BS208B |
|---|---|---|
| Viewing Head | Siedentopf Binocular Viewing Head at 30° IncIined Interpupillary (55-75mm) | Sliding Binocular Head lnclined at 45° interpupillary (55-75mm) |
| Eyepiece | Wide Field Eyepiece WF10x18mm | |
| Nosepiece | Quadruple Nosepiece | |
| Objective | Achromatic Objective 4X,10X,40X,100X | |
| Stage | Double Layers Mechanical Stage 140x135mm/ 75x50mm | |
| Condense | Abbe NA1.2５ with Iris Diaphragm & Filter | |
| Focusing System | Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 28mm | Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 24mm |
| Illumination | S-LED Illumination, Brightness Adjustable | |
| Halogen Lamp 100V-240V/ 6V20W | ||
| Plan-concave Mirror | ||
| Filter | White Filter | |
| Package | Carton | |
| Shipping Size (W×D×H) (mm) | 360x260x470 | |
| Gross Weight (kg) | 7 | |
Biological Microscope Features:
The MSC-BH208B and MSC-BS208B microscopes are designed to provide accurate and versatile microscopes for various scientific and research applications. The tilting binocular viewing head provides a comfortable and ergonomic viewing experience and offers greater flexibility in viewing setup.
It is equipped with wide-field eyepieces (WF10X18 mm) to ensure clear and detailed images for a wide range of specimen types.
The double-layered mechanical stage allows for precise specimen manipulation and positioning. Abbe spotting scope with NA1.25, iris diaphragm and filters for enhanced contrast and illumination control for optimal microscopic performance.
A coaxial coarse and fine adjustment system with a 0.002 mm fine adjustment range provides the precise focusing capability.
The S-LED illumination provides efficient illumination with adjustable brightness. An included white filter improves illumination conditions for specific microscopic techniques.
