tlead-1390 - AMF018 Ultrasonic Thickness Gauge

AMF018 Ultrasonic Thickness Gauge (tlead-1390) Products

Name	AMF018 Ultrasonic Thickness Gauge
Code	tlead-1390
Type	Standard
Brand	Amtast
Category	Test Instruments
subcategory	Thickness Meter -Ultrasonic
Unit	pcs (pcs)
In Stock	Yes
Berminat hub kami:

Product details for Invoice

Ultrasonic Thickness Gauge AMF018 *Measuring range: 1.2~220mm (Steel) *Accuracy: (1%H+0.1)mm *Resolution: 0.1mm *Sound velocity range: 1000~9999m/s *Working frequency: 5MHz *Minimum limit for tube measuring: 20*3mm (Steel) *Auto calibration

Product Details

Ultrasonic Thickness Gauge AMF018

*Measuring range: 1.2~220mm (Steel)

*Accuracy: ±(1%H+0.1)mm

*Resolution: 0.1mm

*Sound velocity range: 1000~9999m/s

*Working frequency: 5MHz

*Minimum limit for tube measuring: Φ20*3mm (Steel)

*Auto calibration to assure the accuracy

*Auto linear compensation: this advanced software program enhances the precision by correcting the non-linear accuracy of transducer.

*Data store/ Data recall/ Data delete function

*Sound velocity measurement
