TIME7120/TIME7122/TIME7126 vibration meter is equipped with acceleration integrated sensor, which makes it has the advantage of being small and light, portably to carry. It is mainly used for the quick check of motor, electric fan, pump, air compressor, machine tools and so on, it is also used for the preventive examination of malfunction of mechanical equipments.



Used for fast failure detecting of motor, electric fan, pump, air compressor, machine tools and so on

Compact size, small Weight, easy handling

Prompt testing of vibration on the workshop machines

For quick checking of unbalance misalignment, bearings and gears

Guard against mechanical malfunction

Holding tested value for 40 seconds

Automatic switch off after 40 seconds

TIME7120 is used specially for velocity testing

TIME7122 is used specially for displacement testing

TIME7126 is used for testing of acceleration, velocity and displacement

Model	TIME7120	TIME7122	TIME7126
Parameters	RMS of vibration, velocity (mm/s)	Displacement	Acceleration, Velocity, Displacement
Testing range	Velocity: 0.1mm/s~199.9mm/s	Displacement: 0.01~1.999mm (peak~peak)	Acceleration:0.01m/S2-199.9m/S2 (peak) Velocity: 0.01mm/s-199.9 mm/s (RMS) Displacement: 0.001~1.999mm (peak-peak)
Frequency range	Velocity:10Hz~1kHz	Displacement: 10Hz~500Hz	Acceleration: 10Hz ~ 1kHz; Velocity: 10Hz ~ 1kHz; Displacement:10Hz ~ 500Hz
Tolerance	±5%
Display	31/2 digits LCD
Power supply	two button batteries (LR44 or SR44)
Battery capacity	Approx. 4.5 hours working continuously
Operating Temperature	0ºC~40ºC
Humidity	<85%
Dimensions (mm)	150×22×18
Weight (g)	55 (including batteries)
