| Name | Waste Gas Collection Hood WGCH-08/10/15/20 |
| Code | scitek-0890 |
| Type | Standard |
| Brand | Scitek |
| Category | Organic Element Analysis and Pretreatment |
| subcategory | Kjeldahl System |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Collection port : 8/10/15/20
Extraction opening : 1/2
Sizes(W×D×H)(mm) : 300x240x170; 300x240x170; 300x150x160; 250x150x160
Waste Gas Collection Hood Specifications:
| Model | WGCH-08 | WGCH-10 | WGCH-15 | WGCH-20 |
|---|---|---|---|---|
| Collection Port | 8 | 10 | 15 | 20 |
| Extraction Opening | 1 | 1 | 2 | 2 |
| Sizes(W×D×H)(mm) | 300x240x170 | 300x240x170 | 300x150x160 | 250x150x160 |
| Shipping Size(W×D×H)(mm) | 420x320x320 | 470x370x370 | 470x370x370 | 490x500x470 |
| N.W./G.W. (kg) | 2.4/4 | 2.4/5 | 3.2/6 | 4.2/6 |
Waste Gas Collection Hood Feature:
This exhaust waste gas collection hood is specially designed to collect acid gas for the digestion furnace. It can collect a large amount of acid gas (acid mist) generated during the sample digestion process through this collection device and then process it through the neutralization device. It ensures that the treated acid gas (acid mist) can be discharged according to the standard.
The sealing cap is made of high-temperature and strong acid-resistant PTFE material, which can effectively prevent leakage.
A small flapper goes deep into the pipe to collect acid gas, which is highly reliability.
The shell is made of a welded stainless steel plate, which is corrosion-resistant and can ensure long-term use.
The collection device provides a variety of specifications, convenient for users to choose according to their needs.
The backup equipment is perfect and has good expandability, which can be configured and expanded according to the actual situation.
