Graphite Digestion Furnace GDF-10L/15L/20L (scitek-0886) Products
| Name | Graphite Digestion Furnace GDF-10L/15L/20L |
| Code | scitek-0886 |
| Type | Standard |
| Brand | Scitek |
| Category | Organic Element Analysis and Pretreatment |
| subcategory | Kjeldahl System |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Product details for Invoice
Model : GDF-10L; GDF-15L; GDF-20L
Heating Module Material : 6061 aluminum alloy
Designed Temperature : 400℃
Temperature Control Accuracy : ±1℃
Control Mode : Single point heating
Heating Module Material : 6061 aluminum alloy
Designed Temperature : 400℃
Temperature Control Accuracy : ±1℃
Control Mode : Single point heating
Product Details
Graphite Digestion Furnace Specifications:
| Model | GDF-10L | GDF-15L | GDF-20L |
|---|---|---|---|
| Operating System | 5.5-inch color touch screen | ||
| Number of Sample Holes | 10 holes | 15holes | 20holes |
| Aperture | Φ43.5mm | ||
| Heating Module Material | 6061 aluminum alloy | ||
| Designed Temperature | 400℃ | ||
| Temperature Control Accuracy | ±1℃ | ||
| Heating Rate | ≈6-15℃/min | ||
| Control Mode | Single point heating | ||
| Recipe Management | 9 groups | ||
| Timing Shutdown | 1-999 minutes | ||
| Power Supply | AC220V/50Hz | ||
| Heating Power | 2KW | 3KW | 4KW |
| Size(W×D×H)(mm) | 439x387x533 | 490x387x533 | 542x387x533 |
| Shipping Size(W×D×H)(mm) | 690x530x650 | ||
| N.W./G.W. (kg) | 18/27 | 21/31 | 26/35 |
Graphite Digestion Furnace Feature:
Over-temperature protection sensor on the shell's surface: when the furnace body's surface temperature is too high, it will automatically alarm and stop.
High-definition display direct setup, easy and fast operation
The colors of the function pages are differentiated from those of the application pages for easy identification.
Single-point heating, curve heating dual mode optional
Segmented power supply, anti-power failure recovery, and restart function can avoid potential risks.
