Viscometer VSC-LD/RD/HD Series (scitek-0454) Products
| Name | Viscometer VSC-LD/RD/HD Series |
| Code | scitek-0454 |
| Type | Standard |
| Brand | Scitek |
| Category | Physical Measurement |
| subcategory | Viscometer |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Product details for Invoice
Model : VSC-LDV1H; VSC-RDV1H; VSC-HDV1H; VSC-LDV2H; VSC-RDV2H; VSC-HDV2H
Measuring Range (mPa·s) : 10~1M; 100~10M; 800~80M; 5~1M; 50~10M; 400~80M
Number of Spindles : 4 types(21, 27, 28, 29)
Accuracy : ±1%(FS)(Newtonian Fluid)
Repeatability : ±0.5%(FS)(Newtonian Fluid)
Measuring Range (mPa·s) : 10~1M; 100~10M; 800~80M; 5~1M; 50~10M; 400~80M
Number of Spindles : 4 types(21, 27, 28, 29)
Accuracy : ±1%(FS)(Newtonian Fluid)
Repeatability : ±0.5%(FS)(Newtonian Fluid)
Product Details
Viscometer Features:
DV-H series digital high temperature viscometer products below are composed of viscometers and special temperature-controlled heaters. They are used to measure hot melt adhesive, asphalt, paraffin, high polymer, etc. dissolved after heating and can directly display the measurement data. DV-2H series products can display shear Rate and shear stress. Some products can be equipped with optional data collection analysis and drawing software to collect and analyze data, display and record the viscosity-temperature curve throughout the process. The product measurement performance has achieved the international advanced level
Viscometer Specifications:
| Series | DV-1H | DV-2H | ||||
|---|---|---|---|---|---|---|
| Model | VSC-LDV1H | VSC-RDV1H | VSC-HDV1H | VSC-LDV2H | VSC-RDV2H | VSC-HDV2H |
| Measuring Range(mPa·s） | 10~1M | 100~10M | 800~80M | 5~1M | 50~10M | 400~80M |
| Rotating Speed (RPM) | 0.1～99.9 | 0.1 ～ 200 | ||||
| Number of Spindles | 4 types (21, 27, 28, 29) | |||||
| Accuracy | ±1%(FS)(Newtonian Fluid) | |||||
| Repeatability | ±0.5%(FS)(Newtonian Fluid) | |||||
| Sample Capacity (mL) | 10～20 | |||||
| Temperature Control Range (℃) | RT+5~300 | |||||
| Temperature Control Accuracy(℃) | ±0.1 | |||||
| Power Supply | AC100~240V, 50/60Hz | |||||
| LCD Screen Display | The LCD screen can display the viscosity, speed, torque, spindle and the maximum viscosit can be measured in the current spindle speed value. | |||||
| Shipping Size (WxDxH)(mm) | Package 1: 400x350x380 Package 2: 400x350x560 | |||||
| G.W(kg) | 15 | |||||
Apparatus to be equipped
| Digital viscosity meter | 1 pce | Ascending and falling | 1 set |
|---|---|---|---|
| Frame and Pipe | 1 set | Power Adapter | 1 pce |
| Standard Spindle | 1 set | Spanner | 1 pce |
| Seat and Leveling Feet | 1 set | RTD Temperature Probe | 1 pce |
| Temperature Controller | 1 pce | Heating Furnace | 1 pce |
| Insulation Cover | 1 pce | Special Tweezers | 1 pce |
| Position Bracket | 1 pce | Connect Cable | 1 pce |
| Power Cord | 1 pce | Connection Hook | 2 set |
