tlead-0868 - TM-8812 TM-8812C Ultrasonic Thickness Meter

TM-8812 TM-8812C Ultrasonic Thickness Meter (tlead-0868) Products

Name	TM-8812 TM-8812C Ultrasonic Thickness Meter
Code	tlead-0868
Type	Standard
Brand	Amtast
Category	Test Instruments
subcategory	Thickness Meter -Ultrasonic
Unit	pcs (pcs)
In Stock	Yes
Berminat hub kami:

Product details for Invoice

Ultrasonic Thickness Meter TM-8812 Features * Wide Measuring Range and high resolution. With high power emission and broad band receiving sensitivity, the gauge can match probes of different frequencies. That makes it easy to measure the rou

Product Details

Ultrasonic Thickness Meter TM-8812 TM-8812C

Features

1. Wide Measuring Range and high resolution. With high power emission and broad band receiving sensitivity, the gauge can match probes of different frequencies. That makes it easy to measure the rough surface, even cast iron. It is widely used in almost all kinds of industries.

2. Applicable to measure the thickness of many materials, e. g. Steel, Cast iron, Aluminum, Red copper, Brass, Zinc, Quartz glass, Polyethylene, PVC, Gray cast iron, Nodular cast iron.

3. Used the exclusive Micro-computer LSI circuit and crystal time base to offer high accuracy measurement & fast measuring time.

4. Using the latest high performance and low power consumption microprocessor technology.

5. Automatic memory material code and sound velocity value, convenient to use.

6. Use USB/RS-232 data output to connect with PC. (Optional)

7. Provide Bluetooth data output choice. (Optioanl)

SPECIFICATIONS

1. Display: 4 digits,10 mm LCD

2. Range: 1.0~200mm (45# steel )

3. Velocity Range: 1000~9000 m/s

4. Resolution: TM-8812: 0.1 mm/0.001inch; TM-8812C: 0.01 mm/0.0001inch

5. Accuracy: ±(0.5%n+0.1)

6. Power Supply: 4x1.5v AAA (UM-4) battery
