| Name | Benchtop Conductivity/DO Meter |
| Code | scitek-0741 |
| Type | Standard |
| Brand | Scitek |
| Category | PH And Electrochemistry |
| subcategory | Multiparameter Meter |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Resolution : 0.01/0.1/1μS/cm; 0.01/0.1mS/cm
Accuracy : Electrode: ±0.5% FS, Meter: ±0.8% FS
Temp. compensation Range : (0 ~ 50)℃, auto
Electrode Constant : 0.1/0.5/1/5/10/50/100 cm-1
Reference Temp. : 25℃, 20℃, 18℃
External Size : 215x170x40mm
This benchtop conductivity/DO meter is perfect for simplified, affordable laboratory testing and data logging.
Benchtop Conductivity/Dissolved Oxygen Meter Specifications:
| Model | CON-DOB906 | |
|---|---|---|
| Conductivity | Measuring Range | Conductivity: (0.00~20.00)μS/cm (20.0~200.0)μS/cm (200~2000)μS/cm (2.00~20.00)mS/cm (20.0~200.0)mS/cm (200~2000)mS/cm(K=10) |
| TDS: (0 ~ 100)g/L | ||
| Salinity: (0 ~ 100)ppt | ||
| Resistivity: (0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
| Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
| Temp. Compensation Range | (0 ~ 50)℃, auto | |
| Electrode Constant | 0.1/0.5/1/5/10/50/100 cm-1 | |
| Reference Temp. | 25℃, 20℃, 18℃ | |
| DO | Measuring Range | (0 ~ 20.00) mg/L(ppm) (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm) 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L | |
| Response Time | ≤30s (25℃, 90%response) | |
| Residual Current | ≤0.1 mg/L | |
| Temp Compensation | (0 ~ 45)℃ (automatic) | |
| Salinity Compensation | (0 ~ 45) ppt (automatic) | |
| Pressure Compensation | (80 ~ 105) kPa (automatic) | |
| Automatic Calibration | Air saturated by water; water saturated by air | |
| Electrode Type | Polarographic | |
| Temperature | Range | (-10 ~ 110)℃ |
| Resolution | 0.1℃ | |
| Accuracy | 5 ~ 60℃: ±0.5℃ Others: ±1.0℃ | |
| Other Parameters | Display | 6.5-inch LED screen |
| Data Storage | 1000 sets | |
| Power | 12V (110-220, 50-60Hz adapter) | |
| Communication Interface | USB, RS232, Bluetooth | |
| Size & Weight | 240×170×70mm/600g | |
| Working Conditions | Temperature | 5 ~ 35 ℃ |
| Humidity | ≤80% | |
| IP grade | IP54 | |
| Meter Kits | 1) Conductivity & DO Meter | |
| 2) Electrode holder | ||
| 3) Conductivity electrode (K=1) | ||
| 4) DO electrode | ||
| 5) Temperature probe | ||
| 6) DO filling solution | ||
| 7) Membrane cap | ||
| 8) Cathode polishing paper | ||
| 9) Power adapter | ||
| External Size | 215x170x40mm | |
| Shipping Size | 475x430x75mm | |
| Net/Gross Weight (KG) | 0.6/3 | |
Benchtop Conductivity/Dissolved Oxygen Meter Features:
6.5-inch LED screen with concise and friendly-use interface.
Built-in microprocessor chip has Intelligent functions such as automatic calibration, ATC, data storage, clock display, USB output, function settings, wireless printing, and self-diagnosis information, etc.
It supports wireless bluetooth printing. Real-time data transfer to mobile phone via bluetooth is optional.
Smart electrode status display to ensure accurate use.
Adopt advanced conductivity measurement technology, with conductivity electrode (K=1), it can meet measuring accuracy requirement for range of 0.5μS/cm ~ 200mS/cm.
It has functions of ATC, auto salinity compensation and auto pressure compensation.
Polarographic DO electrode, short polarization time (3-5 mintues).
Omron long lasting and light touch key can be used more than 100,000 times.
Auto recognition of 8 conductivity standard solution with 2 kinds of options: Europe & USA, and China.
Can store 1000 sets of test data, which can be saved and transferred to USB memory stick and opened with Excel.
