Multi-Parameter Patient Monitor (scitek-0630) Products
| Name | Multi-Parameter Patient Monitor |
| Code | scitek-0630 |
| Type | Standard |
| Brand | Scitek |
| Category | Medical Device |
| subcategory | Patient Monitor |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Product details for Invoice
Model : MPM-IT
Heart Rate : 15-300 BPM (Adult);15-350 BPM (Neonatal)
Resolution : 1 BPM
Accuracy : ±1%
Sensitivity : >200 uV(Peak to peak)
Multi-parameter patient monitors are easy to use and can be easily updated and reconfigured.
Heart Rate : 15-300 BPM (Adult);15-350 BPM (Neonatal)
Resolution : 1 BPM
Accuracy : ±1%
Sensitivity : >200 uV(Peak to peak)
Multi-parameter patient monitors are easy to use and can be easily updated and reconfigured.
Product Details
Multi-Parameter Patient Monitor Features:
12.1-inch touch screen display
USB interfaces support easy software upgrade and data transfer
Compatible with Central Monitoring System (CMS)
Three Working Modes: Monitoring, Surgery and Diagnosis
Simple and friendly operating display interface.
Multi-display modes suitable for different applications: Standard Interface, Large font, ECG Standard Full Display, OXY, Trend Table, BP Trend
Built-in high capacity battery up to 3 hours of continuous work
VGA output for external display
Multi-Parameter Patient Monitor Specifications:
| Model | MPM-IT | ||
|---|---|---|---|
| ECG | Lead Mode | 5 Leads (I, II, III, AVR, AVL, AVF, V) | |
| Gain | 2.5mm/mV; 5.0mm/mV; 10mm/mV; 20mm/mV | ||
| Heart Rate | Heart Rate | 15-300 BPM (Adult); 15-350 BPM (Neonatal) | |
| Resolution | 1 BPM | ||
| Accuracy | ±1% | ||
| Sensitivity | >200 uV(Peak to peak) | ||
| ST Measurement Range | Measurement Range | -2.0 ~ +2.0 mV | |
| Accuracy | -0.8mV~+0.8mV: +0.02mV or ±10%, which is greater | ||
| Other Range | unspecified | ||
| Sweep Speed | 12.5 mm/s, 25mm/s, 50mm/s | ||
| Bandwidth | Diagnostic | 0.05~130 Hz | |
| Monitor | 0.5~40 Hz | ||
| Surgery | 1~20 Hz | ||
| SpO2 | Measuring Range | 0~100 % | |
| Resolution | 1% | ||
| Accuracy | 70%~100% (±2 %) | ||
| Pulse Rate | Range | 20-250 BPM | |
| Resolution | 1 BPM | ||
| Accuracy | ±3 BPM | ||
| Optional Parameters | Recorder (Printer) | ||
| Central monitoring system | |||
| Dual IBP | |||
| Etco2 | |||
| 12-lead ECG | |||
| Nellcor SpO2 | |||
| Sun Tech NIBP | |||
| NIBP | Method | Oscillometry | |
| Measure mode | Manual, Auto, STAT | ||
| Unit | mmHg, kPa | ||
| Measure and alarm range： | |||
| Adult Mode | SYS | 40~280mmHg | |
| DIA | 10~225 mmHg | ||
| MEAN | 20~240 mmHg | ||
| Pediatric Mode | SYS | 40~220 mmHg | |
| DIA | 10~160 mmHg | ||
| MEAN | 20~170 mmHg | ||
| Neonatal Mode | SYS | 40~135 mmHg | |
| DIA | 10~100 mmHg | ||
| MEAN | 20 ~110 mmHg | ||
| Resolution | 1 mmHg | ||
| Accuracy | ±5 mmHg | ||
| TEMP | Measure and Alarm Range | 0~50℃ | |
| Resolution | 0.1℃ | ||
| Accuracy | ±0.1℃ | ||
| RESP | Method | lmpedance between RA-LI or RALA | |
| Measurement Range | Adult | 10~120 BrPM | |
| Neonatal/Pediatric | 7~150 BrPM | ||
| Resolution | 1 BrPM | ||
| Accuracy | ±2 BrPM | ||
| Power Supply | AC100-240V,50/60Hz | ||
| Shipping Size(W×D×H)(mm) | 370x280x360 | ||
| G.W. (kg) | 5 | ||
| Standard Configuration | |||
| No. | ltem | Qty | |
| 1 | Main Unit | 1 | |
| 2 | 5-lead ECG cable | 1 | |
| 3 | Disposable ECG Electrode | 6 | |
| 4 | Adult SpO2 probe | 1 | |
| 5 | Adult NIBP Cuff | 1 | |
| 6 | Temperature Probe | 1 | |
| 7 | NlBP Extension Tube | 1 | |
| 8 | Power Cable | 1 | |
| 9 | User Manual | 1 | |
| 10 | Fuse | 3 | |
