MJ6132TY Precision Panel Saw (tlead-1565) Products
| Name | MJ6132TY Precision Panel Saw |
| Code | tlead-1565 |
| Type | Standard |
| Brand | Amtast |
| Category | Wood Machines |
| subcategory | Panel Saw |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Product details for Invoice
MJ6132TY Precision Panel Saw Dimension of sliding table: 3200370mm Gross cut capacity: 3200mm Width of cut between saw blade and rip fence: 1250mm Saw blade diameter: 300mm(250-315) Height of cut: 80mm Diameter of guide shaft spindle; 55mm S
Product Details
MJ6132TY Precision Panel Saw
Dimension of sliding table: 3200×370mm
Gross cut capacity: 3200mm
Width of cut between saw blade and rip fence: 1250mm
Saw blade diameter: φ300mm(φ250-φ315)
Height of cut: 80mm
Diameter of guide shaft spindle; 55mm
Speed of main saw spindle: 4000/6000rpm
Main spindle diameter: φ30mm
Tilting saw blade: 0-45°
Main motor: 4KW
Scoring saw blade diameter: φ120mm
Speed of scoring saw blade: 8000r/min
Scoring spindle diameter: φ20mm
Scoring motor: 0.75kw
Net weight :685kg
weight: 806kg
Overall dimensions :3250×3150×900mm
