| Name | Automatic Melting Point Apparatus, Touch Screen |
| Code | scitek-0907 |
| Type | Standard |
| Brand | Scitek |
| Category | Physical Measurement |
| subcategory | Melting Point Tester |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Capillary Position Capacity : 4
Capillary Size Inner : 0.9~1.1mm
Magnification of Lens : 8
Display : Color 8-inch Touch Screen
Shipping Size (WxDxH)(mm) : 470x345x390
The melting point apparatus are fast and accurate, and fully automatic operation ensures that every user can analyze samples easily.
MPA-50, MPA-70, MPA-90 automatic video melting point apparatus perfectly integrate video technology into melting point measuring. It not only provides users with reliable melting point test result, but also intuitively displays temperature curve and real-time video image, and achieves the function of save, replay the video and so on . It also provides better help for users to observe melting process of sample.
Automatic Melting Point Apparatus Specifications:
| Model | MPA-50 | MPA-70 | MPA-90 |
|---|---|---|---|
| Capillary Position Capacity | 4 | ||
| Capillary Size | inner 0.9~1.1mm | ||
| Magnification of Lens | 8 | ||
| Display | Color 8-inch Touch Screen | ||
| Temperature Range | RT-350℃ | RT-400℃ | RT-400℃ |
| Temperature Accuracy | 0.4 at 200℃; 0.7 at 300℃ | ||
| Temperature Resolution | 0.1℃ | 0.01℃ | |
| Temperature Repeatability | 0.2℃ | ||
| Temperature Gradients | 0.1℃-20℃ | ||
| Video & Camera | Video & Camera | ||
| Video Replay | yes | ||
| Automatic Find Melting Point | Automatic | ||
| Storage Capacity | 16G | 32G | 128G |
| Graphic | 100 | 200 | 500 |
| Methods Storage | 30 | 80 | 200 |
| Communication Ports | USB×3, RS232, Wi-Fi, RJ45 | ||
| Printer | Laser printer/ Thermal printer | ||
| ID Management | 20 | 30 | 100 |
| Authorization Management | Yes | Yes | Yes |
| Audit Trial | No | Yes | Yes |
| FDA 21 CFR Part11 | No | Yes | Yes |
| Shipping Size (WxDxH)(mm) | 470x345x390 | ||
| Gross Weight (KG) | 8 | ||
Automatic Melting Point Apparatus Features:
The melting point apparatus includes a color display to observe the phase transition, is equipped with a video camera and a video replay function which allows reviewing the melting point determination .
Max concurrent sessions 4 samples each batch, record and track each result independently, meet FDA 21CFR part 11 requirements.
Adopt User ID management function. Users ID are available for adding, deleting and jurisdiction setting.
Adopt a 8 inch capacitive touch screen, with the brilliant Android system, let the operating easier.
The methods, atlas and detailed result are available for storage. Connecting printer or all data export are both available.
