Ion Chromatograph (scitek-0658) Products
Name Ion Chromatograph
Code scitek-0658
Type Standard
Brand Scitek
Category Chromatography Systems
subcategory Ion Chromatography Instruments
Unit pcs (pcs)
In Stock Yes
Berminat hub kami: wa chat
Product details for Invoice
Model : IC-1200
Tubing Flow Rate Range : 0.001-10.000 mL/min
Maximum Pressure : ≥35 MPa
Flow Stability : ≤0.1% (at 1.0 mL/min)
Flow Accuracy : ±0.1% (at 1.0 mL/min)
Ion chromatography products can perform suppressed or non-suppressed conductivity detection and amperometric detection, providing more comprehensive analytical results for different types of samples.
Product Details

The IC-1200 ion chromatograph seamlessly integrates exceptional detection sensitivity, operational stability, and versatile modular functionality. Tailored to meet diverse customer testing requirements, it offers configurable detection modes, including direct conductivity detection, suppressed conductivity detection, amperometric detection, and tandem conductivity-amperometric detection. Its adaptability makes it well-suited for a wide range of applications, including environmental monitoring, disease control, pharmaceuticals, chemical industry, metallurgy, hydrogeology, agriculture, feed, electronics industry, power, nuclear energy research, food safety, and scientific research and teaching.

Ion Chromatograph Feature:

  1. The Ion chromatograph has a professional design and modular components with an all-plastic flow path to eliminate dissolved contamination.

  2. 7.0-inch touch screen, full-screen real-time display of several parameters, with system monitoring, real-time operation status monitoring, working parameters adjustment and other functions, easy to use and maintain.

  3. Ion chromatograph adopts industrial-grade electrical components and advanced shielding technology, which greatly improves the sensitivity and stability of the instrument.

  4. It can detect 9 common anions in water (including disinfection by-products).

  5. Ion chromatograph can automatically identify the signal of valve switching position and start the software to analyze automatically, avoiding the error caused by manual operation;

  6. Provides one-key flushing function to simplify the operation of the instrument. At the same time, the host can regularly start the flow path to flush the system components to avoid pipeline crystallization;

Ion Cchromatograph Specifications:

ModelIC-1200
Display7.0-inch touch screen
Chromatography PumpInfusion UnitHigh-pressure, low-pulse dual-plunger series pump
Pump Head MaterialInert PEEK material pump head
Tubing Flow Rate Range0.001-10.000 mL/min
Maximum Pressure≥35 MPa
Flow Stability≤0.1% (at 1.0 mL/min)
Flow Accuracy±0.1% (at 1.0 mL/min)
InhibitorDynamic inhibition capacity100µeq/min
Inhibition background0.6µS/cm
Inhibitor background noise6nS/cm
Inhibitor dead volume50µL
Current range0-300mACurrent setting increment: 0.1mA
Column Temperature OvenTemperature control rangeRT +5℃-85℃
Allowable temperature setting error±0.271℃
Temperature control stability±0.029℃/h
Conductivity DetectorConductivity detection range0-15000µs
Detection cell volume≤0.3µL
Baseline noise≤0.1%
FSBaseline drift<±0.8%FS/30min
Qualitative repeatability (RSD)<0.21%
Detection limitCl-≤0.0005 µg/ml
Linear range≥10²
Linear correlation coefficient≥0.999
Retention time repeatability errorNO3-, SO42-, Na+, and Ca2+ ≤1.0%
