HY3002D-3 HY3003D-3 HY3005D-3 DC Power Supply Triple Output

Specifications:

1. Input Voltage: 110/220V±10%AC

2. Output Voltage: 2×0~30V

3. Output Current:

   1) HY3002D-3: 2×0~2A

   2) HY3003D-3: 2×0~3A

   3) HY3005D-3: 2×0~5A

4. Source Effect: CV≤0.01%±1mV; CC≤0.02%±1mA

5. Load Effect: CV≤0.01%±5mV; CC≤0.02%±5mA

6. Ripple & Noise: ≤1mVrms

7. Fixed Output: 5V/3A

8. Display: Four 3 1/2 digit LCD display

9. Accuracy: V: ±1%±2digits; C: ±2%±2digits

10. Size: 365×265×164mm

11. Weight: 8~12kg
