| Name | Electronic & Digital Heating Mantles |
| Code | biobase-0629 |
| Type | Standard |
| Brand | Biobase |
| Category | Laboratory Temperature Control Equipments |
| subcategory | Heating Mantle |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
*corrosion-resisting and ageing-resistant.
*The internal heater is in hemisphere shape with high efficiency.
*The external material is cold-rolled steel with anti-bacteria powder coating.
*It adopts high-temperature resistant alkali-free glass fiber with good isolation performance.
Model：
Model | HME-I (Electronic Display) / HMD-I(LED Display) | |||||||||
Capacity(ml) | 100 | 250 | 500 | 1000 | 2000 | 3000 | 5000 | 10000 | 20000 | 50000 |
Max. Temp. | 380°C | |||||||||
Working Time | Continuous | |||||||||
Consumption | 100WW | 180WW | 250W | 300W | 500W | 600W | 1000W | 1500W | 2500W | 6000W |
Power Supply | AC220/110V±10%, 50/60HZ | |||||||||
Internal Size (mm) | φ70*40 | φ95*50 | φ150*50 | φ150*70 | φ180*80 | φ200*100 | φ245*150 | φ310*175 | φ380*190 | φ480*270 |
External Size (W*D*H) | 200*215*150mm | 240*260 *170mm | 285*300 *200mm | 355*300 *240mm | 415*370 *270mm | 480*430 *300mm | 540*530 *280mm | 665*450 *550mm | ||
Packing Size (W*D*H) | 260*265*237mm | 250*70 *190mm | 300*310 *210mm | 300*310 *245mm | 370*380 *285mm | 500*440 *320mm | 560*560 *290mm | 775*775 *560mm | ||
Net Weight | 1.7kg | 1.8kg | 1.8kg | 2.7kg | 4kg | 4.5kg | 7kg | 10kg | 13kg | 53kg |
Gross Weight | 3.5kg | 2kg | 2kg | 4kg | 5.5kg | 6kg | 9kg | 13kg | 15kg | 68kg |
