| Name | Fully Automatic Biochemistry Analyzer |
| Code | scitek-0585 |
| Type | Standard |
| Brand | Scitek |
| Category | Clinical Analyzers and Reagents |
| subcategory | Biochemistry Analyzer |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Test Method : 1 point end, 2 point end, Fixed-Time, Kinetics
Machine Type : Random access, open reagent & locked reagent (optional)
Test Principle : Colorimetric method, turbidimetry
Sizes(W×D×H)(mm) : 750x550x490;750x475x535;780x565x1120;
870x690x740;920x650x1120;1110x765x1150;
This biochemistry analyzer is suitable for analysing biochemical indicators in biological samples such as serum and urine to assist doctors in disease diagnosis and treatment monitoring.
Fully Automatic Biochemistry Analyzer Specifications:
| Model | BA-120 | BA-160 | BA-220 | BA-280 | BA-380 | BA-480 |
|---|---|---|---|---|---|---|
| Machine Type | Random access, open reagent & locked reagent (optional) | |||||
| Test Speed | Constant 120 tests/hour (Mono reagent or double reagent) | Constant 150 tests/hour (Mono reagent or double reagent) | Constant 200 tests/hour (Mono reagent or double reagent) | Constant 200 tests/hour (Mono reagent or double reagent) | Constant 300 tests/hour (Mono reagent or double reagent) | Constant 400 tests/hour (Mono reagent or double reagent) |
| Test Principle | Colorimetric method, turbidimetry | |||||
| Test Method | 1 point end, 2 point end, Fixed-Time, Kinetics | |||||
| Calibration Type | Linear & nonlinear | |||||
| Sample Unit | ||||||
| Sample Tray | 40 sample positions | 70 sample positions | 120 sample positions | |||
| Sample Tube | Micro cup & test tube & blood collection tube can be used. (Φ12 -13)mmx(25-100 )mm | |||||
| Sample Volume | 2-30µL step by 0.1µL | |||||
| Sample Probe | Liquid surface detection, timely tracking for liquid volume. Collision avoidance | |||||
| Sample Barcode | Sample barcode reader (optional) | |||||
| Reagent Unit | ||||||
| Reagent Tray | 80 reagent positions (40 for Rl & 40 for R2), Non-stop cooling system with peltier pad inside, 24 hours 2℃-14℃, open system, could accept any reagent | 70 reagent positions, Non-stop cooling system with peltier pad inside, 24 hours 2℃-14℃, open system, could accept any reagent | 90 reagent positions, Non-stop cooling system with peltier pad inside, 24 hours 2℃-14℃, open system, could accept any reagent | |||
| Reagent Volume | 20-300µL, step by 1µL | |||||
| Reagent Needle | Liquid surface detection, timely tracking for liquid volume. Collision avoidance | |||||
| Regent Barcode | Regent barcode reader (optional) | |||||
| Reaction Unit | ||||||
| Reaction Tray | 50 reaction cuvettes, new amorphous optical plastics reaction cups, perfect transmittance. | 44 reaction cuvettes, new amorphous optical plastics reaction cups, perfect transmittance. | 90 reaction cuvettes, new amorphous optical plastics reaction cups, perfect transmittance | |||
| Reaction Volume | 150uL-330uL | |||||
| Reaction Time | 10 minutes | |||||
| Temperature | Peltier pad incubation system, reaction temperature (37℃ ±0.1℃) | |||||
| Mixing System | ||||||
| Mixer | Paddle-type mixing, effective reducing of carry-over | |||||
| Optical System | ||||||
| Light Source | Halogen lamp | |||||
| Wavelength | 340nm; 405nm; 450nm; 505nm; 546nm; 578nm; 630nm;700nm(4 more options) | |||||
| Absorbance Range | 0-4.0 Abs | |||||
| Resolution | 0.0001 Abs | |||||
| Operating System | ||||||
| Operation System | Windows XP, Windows 7, Windows 8, Windows 10 | |||||
| Report Printing | 6 formats optional, support custom pattern | |||||
| Interface | TCP/IP network interface | |||||
| Working Conditions | ||||||
| Power Supply | AC 220/110V ±10%, 50/60Hz, 650W | |||||
| Water Consumption | 6L/hour(maximum) | 8L/hour(maximum) | 12L/hour (maximum) | 15L/hour (maximum) | ||
| Language | All languages | |||||
| Sizes(WxDxH)(mm) | 750x550x490 | 750x475x535 | 780x565x1120 | 870x690x740 | 920x650x1120 | 1110x765x1150 |
| Shipping Size (WxDxH)(mm) | 890x710x760 | 890x740x1390 | 890x710x760 | 1050x800x1380 | 1240x910x1360 | |
| N.W./G.W. (kg) | 70/80 | 68/88 | 96/145 | 70/85 | 127/180 | 165/220 |
Data processing : Automatic calibration, test combination, effective time management of reagents, serum index, whole process detection, linear expansion of enzyme, blank deduction,dirty cuvette memory, cross infection prevention, patient information memory and association input, automatic report audit, data fuzzy query, report statistics and printing, reference range grading, alarm information classification, user operation privilege classification management.
Fully Automatic Biochemistry Analyzer Features:
Internal and external mirror polishing, internal and external probe cleaning.
Standard mixing programme for excellent mixing results
80 reagent positions, 40 sample positions
Uninterrupted cooling system with built-in Peltier pads, 24 hours 2°C-14°C
The user-friendly software interface is simple and easy to operate
Automatic sample dilution (decrease, increase, normal)
Automatic reaction result checking and alarm, automatic calibration result checking and alarm logging
Linear and non-linear calibration, up to 8-point multi-point calibration
Quality control applies to westbound, LT charts, cumulative
A dedicated sampling probe equipped with a sensitive liquid sensor for timely reagent and sample residue feedback.
Teflon coating mixer. No water droplets (reduced residue)
