| Name | Flow Rate Peristaltic Pump, LCD Display |
| Code | scitek-1045 |
| Type | Standard |
| Brand | Scitek |
| Category | Pumps |
| subcategory | Peristaltic Pump |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Speed Range : 0.1~150rpm; 0.1~350rpm; 0.1~600rpm
Display Method : 128x32 graphical dot-matrix LCD display
Angular Resolution : 0.1rpm
Flow Resolution : 0.001mL/min
External Size(LxWxH)(mm) : 138×153×220; 290×200×206;
By leveraging advanced motor control technology, this flow rate peristaltic pump exceptional accuracy and reliability, making it ideal for applications requiring precise fluid handling.
Flow Rate Peristaltic Pump Features:
This product features a high-precision external drive for stepper motor microstepping, ensuring smooth operation and minimal vibration.
Physical buttons, 128x32 graphical dot-matrix LCD display, distinctive features, and wider application areas,for FPP-101LY and FPP-601LY
Physical buttons for direction control and start/stop, easy and convenient operation; also equipped with a full speed key for rapid filling or emptying.Rotary encoder for speed adjustment for FPP-301LY and FPP-601LY
It is equipped with a timing and quantitative function for FPP-101LY and FPP-601LY, making it suitable for simple filling needs.
It is capable of RS485 communication with a PC, and our company provides free testing software and communication protocols. Only for FPP-301LY and FPP-601LY
Wireless control is supported, allowing for remote wireless operation when used with our company's remote controller.
It also supports mobile phone control, enabling AI-powered operation when paired with IoT technology.
By using optional accessories such as a dispensing controller, foot switch, or relay control module, it can achieve small-batch filling and distribution.
Flow Rate Peristaltic Pump Specifications:
| Model | FPP-101LY | FPP-301LY | FPP-601LY |
|---|---|---|---|
| Speed Range | 0.1~150rpm | 0.1~350rpm | 0.1~600rpm |
| Flow Range | 0.0025~570mL/min | 0.0025~1330mL/min | 0.0025~2280mL/min |
| Display Mode | 128x32 graphical dot-matrix LCD display | ||
| Adjustment Method | Physical button adjustment or external control adjustment | Rotary encoder or external control adjustment | Physical button adjustment or external control adjustment |
| Power Supply | AC90-265V,50Hz/60Hz | ||
| Working Environment | Temperature,0~40℃,Humidity＜80%， No condensation | ||
| IP Grade | IP31 | ||
| Angular Resolution | 0.1rpm | ||
| Flow Resolution | 0.001mL/min | ||
| External Control | Start/stop, direction (switch) Speed (0-5V, 0-10V, 4-20mA0-10KHz optional) | ||
| Interface | RS485 | ||
| External Size (LxWxH)(mm) | 138×153×220 | 290×200×206 | 290×200×206 |
| Power Consumption | <30W | ||
| Drive Weight | 2.35 kg (excluding pump head) | 3.5 kg (excluding pump head) | 3.5 kg (excluding pump head) |
| Suitable pump head & Flow reference (ml/min) | ||||
|---|---|---|---|---|
| Pump head | YZ1515 | YZ2515 | DG1,2,4 (6) | DG1,2,4,6 (10) |
| Tube | 13# 14# 19# 16# 25# 17# 18# | 15# 24# | Wall thickness 0.8-1mm, inner diameter ≤3.17mm | |
| FPP-101LY | ≤570 | 0.17-405 | 0.0025-48 | 0.002-32 |
| FPP-301LY | 0.007-1330 | 0.17~933 | - | - |
| FPP-601LY | 0.007~2280 | 0.17~1600 | - | - |
| Channel | 1 for BT100FC; 1, 2 for BT300FC and BT600FC | 1 for BT100FC; 1, 2 for BT300FC and BT600FC | 1, 2, 4 for BT100FC | 1, 2. 4 for BT100FC |
