Flow Rate Peristaltic Pump, Color Touch Screen (scitek-0307) Products
| Name | Flow Rate Peristaltic Pump, Color Touch Screen |
| Code | scitek-0307 |
| Type | Standard |
| Brand | Scitek |
| Category | Pumps |
| subcategory | Peristaltic Pump |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Product details for Invoice
Model : FPP-100LC; FPP-300LC; FPP-600LC
Speed Range : 0.01-100rpm; 0.01-300rpm; 0.01-600rpm
Display Method : 4.3-inch color LCD
Speed Display Resolutio : 0.01rpm
External Size(LxWxH)(mm) : 155×212×232
This easy-to-use flow rate peristaltic pump is equipped with independent full-speed button, capable of rapid pipeline filling and emptying.
Speed Range : 0.01-100rpm; 0.01-300rpm; 0.01-600rpm
Display Method : 4.3-inch color LCD
Speed Display Resolutio : 0.01rpm
External Size(LxWxH)(mm) : 155×212×232
This easy-to-use flow rate peristaltic pump is equipped with independent full-speed button, capable of rapid pipeline filling and emptying.
Product Details
Flow Rate Peristaltic Pump Features:
4.3-inch industrial-grade true color LCD display, with intuitive interface and convenient touchscreen operation.
Compatible with various pump heads, including YZ1515, YZ2515, and BZ25.
External control interface allows for the control of peristaltic pumps.
With calibration function to ensure high accuracy through calibration.
RS485 communication utilizing modbus protocol, easy to debug and use.
Constructed with a 304 stainless steel metal casing.
Scheduled quantitative function
Flow Rate Peristaltic Pump Specifications:
| Model | FPP-100LC | FPP-300LC | FPP-600LC |
|---|---|---|---|
| Speed Range | 0.01-100rpm | 0.01-300rpm | 0.01-600rpm |
| Display Method | 4.3-inch color LCD | ||
| Interface | RS485 | ||
| Power Consumption | <40W | <50W | <60W |
| External Size (LxWxH)(mm) | 155×212×232 | ||
| IP Grade | IP31 | ||
| Speed Display Resolution | 0.01rpm | ||
| External Control Input Interface | 0-5V, 0-10V, 4-20m, 0-10kHz | ||
| Power Supply | AC90-265V, 50Hz/60Hz | ||
| working Environment | Temperature,0~40℃, Humidity＜80%, No condensation | ||
| Drive Weight | 4.45kg | ||
| Pump Head | YZ1515, YZ2515 DG Series | ||
| Suitable pump head & Flow reference (ml/min) | ||||
|---|---|---|---|---|
| Pump Head | YZ1515 | YZ2515 | DG1, 2, 4 (6) | DG1, 2, 4, 6 (10) |
| Tube | 13# 14# 19# 16# 25# 17# 18# | 15#, 24# | Wall thickness 0.8-1mm, inner diameter ≤3.17mm | |
| FPP-100LC | 0.007~380 | 0.17~270 | 0.002~48 | 0.0015~32 |
| FPP-300LC | 0.007~1140 | 0.17~800 | - | - |
| FPP-600LC | 0.007~2280 | 0.17~1600 | - | - |
| Channel | 1 for BT100FC; 1·2 for BT300FC and BT600FC | 1 for BT100FC; 1·2 for BT300FC and BT600FC | 1, 2, 4 for BT100FC | 1, 2, 4 for BT100FC |
