| Name | Big Forced Air Drying Oven |
| Code | scitek-0025 |
| Type | Standard |
| Brand | Scitek |
| Category | Ovens and Furnaces |
| subcategory | Forced Convection Drying Oven |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
FDO-640; FDO-1000; FDO-1300; FDO-1870; FDO-3070
Capacity : 640L / 1000L / 1300L / 1870L / 3070L
Circulation Mode : Forced air convection
Temperature Range : 640~1000L: RT+10~250℃; 1300~3070L: RT+10~300℃
Timer : 1~9999min(with timing wait function)
The heating chambers of the drying oven offer almost unlimited capacity and are particularly adaptable.
Forced Air Drying Oven Specifications:
| Model | FDO-640B /FDO-640 | FDO-1000B /FDO-1000 | FDO-1300B /FDO-1300 | FDO-1870B /FDO-1870 | FDO-3070B /FDO-3070 | |
|---|---|---|---|---|---|---|
| Capacity(L) | 640 | 1000 | 1300 | 1870 | 3070 | |
| Circulation Mode | Forced convection | |||||
| Size(WxDxH) | Internal (mm) | 800x800 x1000 | 1000x1000 x1000 | 1000x1000 x1300 | 1200x1200 x1300 | 1600x1200 x1600 |
| External (mm) | 940x1000 x1400 | 1040x1200 x1400 | 1230x1200 x1670 | 1330x1400 x1670 | 1750x1400 x1900 | |
| Temperature | Range (℃) | RT+10~250℃ | RT+10~300℃ | |||
| Fluctuation (℃) | ±1 | |||||
| Resolution (℃) | 0.1 | |||||
| Uniformity (℃) | ±3% | |||||
| Sensor | PT100 | |||||
| Controller | PID | |||||
| Display | Digital LCD | |||||
| Timer | 0~9999min(with timing wait function) | |||||
| Material | Internal | B: Iron sheet, Without B: Stainless steel | ||||
| External | Galvanized sheet electrostatic spraying exterior | |||||
| Shelves (Standard / Max ) | 2 / 11 | 2 / 11 | 2 / 15 | 2 / 15 | 2 / 18 | |
| Exhaust Hole | On top or side | |||||
| Safety Device | One key to start overheat power off | |||||
| Electricity | Voltage/ Frequency | 380V, 50/60Hz | ||||
| Consumption (W) | 6000 | 6600 | 9000 | 12000 | 15000 | |
| N.W./G.W. (kg) | 130/200 | 190/260 | 280/350 | 410/480 | 700/800 | |
| Shipping Size (WxDxH) (mm) | 1060x1190 x1520 | 1260x1290 x1520 | 1350x1300 x1890 | 1550x1500 x1890 | 1870x1620 x2230 | |
| Optional | Programmed temperature control instrument, spare shelf, RS485 interface, printer | |||||
Forced Air Drying Oven Features:
Air drying ovens with forced convection circulation mode stand out for their excellent performance and reliability
Drying Oven has a wide temperature range for a variety of applications
Digital LCD display allows the user to precisely control the oven's operating parameters
Timed wait function adds convenience and flexibility to the drying process
The overall construction is made of high quality, corrosion-resistant materials, increasing the robustness of the oven and its resistance to external elements
The air drying oven is equipped with a configurable number of racks, providing flexibility for different sample loads.
Multiple safety features provide security and protection
