| Name | Basic Peristaltic Pump |
| Code | scitek-1039 |
| Type | Standard |
| Brand | Scitek |
| Category | Pumps |
| subcategory | Peristaltic Pump |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Rotating Speed : 0.1~100rpm
Speed Resolution : 0.1rpm
Adjustment Method : Physical button adjustment or external control adjustment
External Size(LxWxH)(mm) : 220×153×138
Basic peristaltic pump for filtration. From laboratory vacuum pumps to peristaltic pumps, there is a wide range of general purpose and manual pumps to choose from.
Basic Peristaltic Pump Features:
Stepper motor subdivision drive, using external drive, has high precision, smooth operation and low vibration.
Physical buttons and green digital display are unique and have a wider range of applications.
Forward rotation, reverse rotation, and external control are indicated by 3 indicator lights; when stopped, the corresponding indicator light flashes.
The physical buttons adjust the speed, direction, and start/stop, making the operation simple and convenient; there is also a full-speed button for quick filling or emptying.
It has a power-off memory function. After power-off, power on again to maintain the data status before power-off.
Supports wireless control and can be used with our company's remote control to achieve remote wireless control.
Supports external signal control such as 0-10kHz, 0-5V, 0-10V, 4-20Ma, etc.
It can be used with optional accessories to achieve small batch filling and distribution
Basic Peristaltic Pump Specifications:
| Model | BPP-100J |
|---|---|
| Rotating Speed | 0.1~100rpm |
| Speed Resolution | 0.1rpm |
| External Control Function | Start, stop, direction (switch signal); speed (0-5V, 0-10V, 4-20mA, 0-10KHz optional) |
| Adjustment Method | Physical button adjustment or external control adjustment |
| Communication Function | Adapted to RS485 communication module, capable of RS485 communication standard (MODBUS protocol) |
| Voltage | AC90-265V, 50Hz/60Hz |
| Power Consumption | <30W |
| Working Environment | Ambient temperature 0~40℃, relative humidity <80% |
| External Size (W×D×H)(mm) | 220×153×138 |
| Weight (Excluding Pump Head) | 2.35kg |
| Protection Level | IP31 |
Configuration
| Model | Applicable pump head | Applicable hose | Flow range (ml/min) | Number of channels |
|---|---|---|---|---|
| BPP-100J | YZ1515 | 13# 14# 19#16# 25# 17#18# | 0.007-380 | 2 |
| YZ2515 | 15#24# | 0.17-270 | 2 | |
| DG-(1,2,4) 6 rollers | Wall thickness 0.8-1mm, inner diameter ≤ 3.17mm | Single channel 0.0025-48 | 1,2,4 | |
| DG-(1,2,4) 10rollers | Single channel 0.002-32 | 1,2,4 |
