AMD001:    5 lines (4V1H)

AMD001A:  2 lines (1V1H)

AMD001B:  3 lines (2V1H)

Specifications:

1. Leveling system: Electronic sensor

2. Wavelength: Vertical and Horizontal Laser: 635nm; Down point: 650nm

3. Working distance: Radius about 10m

4. Leveliing Range: about ±4°

5. Emitting Angle: about 110°

6. Horizontal accuracy: ±1mm/10m

7. Vertical accuracy: ±1mm/5m

8. Down point accuracy: ±1mm/1.2m

9. Perpendicular accuracy: 90°±1'

10. Zenith accuracy: ±1mm/3m

11. Power supply: 2 x 18650 rechargeable battery

12. Working temperature: -10°C ~ 45°C

13. Dimension: Φ110 x 190mm

14. Weight: 1.2kg
