AMA009 Ultrasonic Thickness Meter (tlead-0759) Products
| Name | AMA009 Ultrasonic Thickness Meter |
| Code | tlead-0759 |
| Type | Standard |
| Brand | Amtast |
| Category | Test Instruments |
| subcategory | Thickness Meter -Ultrasonic |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Product details for Invoice
Ultrasonic Thickness Meter TM-1240 Features * Using the latest high performance and low power consumption microprocessor technology. * Automatic memory material code and sound velocity value, convenient to use. * Use USB/RS-232 data output t
Product Details
AMA009 Ultrasonic Thickness Meter
Order Number:
1. AMA009: Standard packing
2. AMA009S: with software
3. AMA009B: with bluetooth
Order Number:
1. AMA009: Standard packing
2. AMA009S: with software
3. AMA009B: with bluetooth
Features
1. Using the latest high performance and low power consumption microprocessor technology.
2. Automatic memory material code and sound velocity value, convenient to use.
3. Use USB/RS-232 data output to connect with PC.
4. Provide Bluetooth data output choice.
Specifications:
Material Selection:
1. CD01: Steel
2. CD02: Cast Iron
3. CD03: Aluminum
4. CD04: Red Copper
5. CD05: Brass
6. CD06: Zinc
7. CD07: Quartz Glass
8. CD08: Polyethylene
9. CD09: PVC
10. CD10: Gray Cast Iron
11. CD11: Nodular Cast Iron
12. XXXX: Sound Velocity
Specifications:
1. Display: LCD
2. Operating Principle: Ultrasonic
3. Measuring Range: 0.75~400mm (45#steel) (Depend on Probe)
4. Resolution: 0.1mm/0.01mm/0.001inch
5. Accuracy: ±0.5%
6. Lower Limit of Pipes: Φ15x2.0mm Φ20x3.0 mm; Determined By Transducer
7. Sound Velocity: 1000~9999 m/s
8. Operating Conditions: Temperature:0~40ºC; Humidity:<85%RH
9. Power Supply: 4x1.5V AAA (UM-4) Battery
10. Dimensions: 140x72x34mm
11. Weight: 185g (Not Including Batteries)
12. Standard Accessories: Main Unit; Standard Probe
13. Optional Accessories: Other Special-purpose Probe; RS-232C Data Cable with Software; Bluetooth Data Adapter with Software
