AE-770 Electrostatic Field Meter

AE-770 is a palm-sized electrostatic measuring device ideal for checking ion balance and Sensor for polarity of static charge.

Features:

1. Measuring polarity and intensity of static charge on parts and assembly lines

2. Checking ion balance performance of various ionizers

Applications:

For checking the performance of ionizers, locating and measuring electrostatic charge build-up, deciding best location for installing ionizers and testing their efficiency, etc.

Technical Specifications:

1. Measuring range:

    1) Static voltage: ±0 ~ ±1.49kV (Low range), ±1.0 ~ ±20.0kV (High range)

    2) Ion balance voltage measuring range 0 ~ ±200V

2. Measuring distance: 25mm ± 0.5 (between charged object and field meter)

3. Accuracy: ±10%

4. Ambient conditions: 10°C ~ 40°C, 68%RH or lower

5. Display: Large LCD display (Digital and bar graph)

6. Power: 9V, 6F22Y

7. Weight with battery Approx. 140g without ion balance plate (Ion balance plate: Approx. 30g)
