Wide Belt Sander SRAP1300T Conveyer Feeding Three Head (tlead-1399) Products
| Name | Wide Belt Sander SRAP1300T Conveyer Feeding Three Head |
| Code | tlead-1399 |
| Type | Standard |
| Brand | Amtast |
| Category | Wood Machines |
| subcategory | Sanding Machine |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Product details for Invoice
Features: Model SRAP1300T is mainly suitable for fine sanding plywood, solid board, block board, wood board etc. Specifications Working width 40-1300mm Working thickness 3-110mm Working length 200mm Feed speed 6-30m/min Main motor power 30k
Product Details
Features:
Model SRAP1300T is mainly suitable for fine sanding plywood, solid board, block board, wood board etc.
Specifications
Working width | 40-1300mm |
Working thickness | 3-110mm |
Working length | ≥200mm |
Feed speed | 6-30m/min |
Main motor power | 30kw,22kw,15kw |
Feeding Motors | 5.5kw |
Size of belt (WXP) | 1330x2620mm |
Working air pressure | 0.55Mpa |
Volume of sucked air | 12000m3/h |
Consumption of compressed air | 0.1m3/h |
Overall dimension (LxWxH) | 2860x2030x2320mm |
Net weight | 7400kg |
| Type | SRP 1600 |
| Working width | 40-1600mm |
| Working thickness | 3-100mm |
| No:1 abrasive belt speed | 20m/s |
| No:2 abrasive belt speed | 17m/s |
| Feed speed | 6-30m/min |
| Size of abrasive belt(W×P) | 1630 × 2500mm |
| Total motor power | 74kw |
| Working air pressure | 0.55MPa |
| Volume of sucked air | 12000m 3 /h |
| Speed of sucked air | 25-30m/s |
| Overall dimension(L×W×H) | 2340×2980×2140mm |
| Net weight | 4500kg |
| All rights for technical modifications reserved. CE approval | |
| Type | SRP 2000 |
| Working width (mm) | 40-2000 |
| Working thickness (mm) | 3-120 |
| No:1 abrasive belt speed | 20m/s |
| No:2 abrasive belt speed | 18m/s |
| Feed speed (m/min) | 6-30 |
| Size of abrasive belt (W x P, mm) | 2020 × 2900 |
| Total motor power | 74.7kw |
| Working air pressure | 0.55MPa |
| Volume of sucked air (M3/h) | 15000 |
| Speed of sucked air | 25-30m/s |
| All rights for technical modifications reserved. CE approval | |
