tlead-1178 - SM2234A PHOTO TACHOMETER (LASER)

SM2234A PHOTO TACHOMETER (LASER) (tlead-1178) Products

Name	SM2234A PHOTO TACHOMETER (LASER)
Code	tlead-1178
Type	Standard
Brand	Amtast
Category	Test Instruments
subcategory	Tachometer
Unit	pcs (pcs)
In Stock	Yes
Berminat hub kami:

Product details for Invoice

SM2234A PHOTO TACHOMETER(LASER) Diisplay 5digit 18mmLCD Range: 2.5~99999 RPM Resolution: 0.1 RPM From:(2.5~999.9RPM) 1 RPM From:((above 1000RPM) Accuracy: (0.05%+1digital) of reading Sampling Time: 0.8second (over 60RPM) Range Select: Auto-r

Product Details

SM2234A PHOTO TACHOMETER (LASER)

Specifications:

1. Diisplay: 5digit 18mm LCD

2. Range: 2.5~99999 RPM

3. Resolution: 0.1RPM (2.5~999.9RPM); 1RPM (above 1000RPM)

4. Accuracy: ± (0.05%+1digital) of reading

5. Sampling Time: 0.8seconds (over 60RPM)

6. Range Select: Auto-range

7. Time Base: 6MHz Quartz crystal

8. Memory: Max. value, Min. value, Last value. Can store 96s data.

9. Detecting Distance: 50mm~500mm

10. Dimension: 155*70*35mm
