| Name | Open-Cup Flash Point Tester |
| Code | biobase-0372 |
| Type | Standard |
| Brand | Biobase |
| Category | Laboratory Analysis Equipments |
| subcategory | Flash Point Tester |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
It is applicable to all petroleum products with flash points above
79°C and below 400°C except fuel oils.
Features:
BK-FP3536:
* It adopts special heating furnace to ensure the safety of test.
* The heating power is continuously adjustable. It can meet requirements
of test.
* The instrument is fully self-contained complete. The operator can do determination as long as connecting with coal gas or other civil gas.
* With fast cooling function, it can improve test efficiency.
BK-FP3536D:
* 8-inch IPS high-definition capacitive screen, the test data and parameters
are displayed by curve in real time
* Automatic measurement of atmospheric pressure, automatic correction
of flash point value.
* Equipped with Bluetooth interface. The user can query test data anytime.
* Electronic ignition, gas flame.
* Remote automatic upgrade to obtain the latest version, remote prediction,
abnormal early warning, comprehensive evaluation and maintenance
of instrument operation status.
Technical Parameters:
Model | BK-FP3536 | BK-FP3536D |
Thermometer | -6°C~400°C. It is the same as thermometer ASTM 11C | |
Ambient Temperature | 15°C-35°C | |
Relative Humidity | ≤85% | |
Consumption | ≤650W | ≤750W |
Test Flame Applicator | It applies the test flash automatically. | |
Heating Device | Furnace heating, no naked fire, explosion prevented. The power is adjustable from OW to 600W | 1. Initial heating: (14~17) °C/min 2. It is (5-6) °C/min after reaching the preset flash point 20 °C |
Igniting Device | (1) Ignition source: coal gas(or civil gas) (2) Flame diameter is 3.2mm~4.8mm | Electric ignition Diameter of igniter: 0.7mm~0.8mm |
Flash Point Determination |
| Range: Ambient to 400°C Accuracy: 0.1 °C |
Power Supply | AC220V±10%, 50Hz | |
Dimension(W*D*H) | 350*290*350mm | 510*320*330mm |
Package Size(W*D*H) | 650*450*420mm | 6690*500*610mm |
Gross Weight | 20kg | 35kg |
