| Name | Multi-row Magnetic Stirring Heating Mantles |
| Code | scitek-0389 |
| Type | Standard |
| Brand | Scitek |
| Category | Hotplates and Stirrers |
| subcategory | Stirring Heating Mantles |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Capacity(ml) : 2×250 / 2×500 / 2×1000 / 4×250 / 4×500 / 4×1000 / 6×250 / 6×500 / 6×1000
Heating Mode : Surface heat conduction
Surface Max. Temperature : 450℃
Temp. Range : RT+vfc20～250℃
Speed Range : 0～1600rpm
Magnetic stirring heating mantles offer powerful stirring speeds up to 1600 rpm and heating temperatures up to 450°C.
Discover the precision and versatility of our Magnetic Stirring Heating Mantles designed for efficient laboratory heating and stirring applications. With advanced surface heat conduction technology, these mantles provide uniform and reliable heating,
Magnetic Stirring Heating Mantles Specifications:
| Model | MHE-SI | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Function | Capacity(ml) | 2×250 | 2×500 | 2×1000 | 4×250 | 4×500 | 4×1000 | 6×250 | 6×500 | 6×1000 |
| Heating Mode | Surface heat conduction | |||||||||
| Surface Max. Temperature | 450℃ | |||||||||
| Temp. Range | Rt+vfc20～250℃ | |||||||||
| Speed Range | 0～1600rpm | |||||||||
| Structure | Heating Element | Nickel chromium alloy wire | ||||||||
| Stir Bar | PTFE | |||||||||
| Outer Shell | Cold rolled steel plate, surface spraying | |||||||||
| Motor Power | 0.01kW | |||||||||
| Heating Power(kW) | 2×0.15 | 2×0.25 | 2×0.35 | 4×0.15 | 4×0.25 | 4×0.35 | 6×0.15 | 6×0.25 | 6×0.35 | |
| Controller | Work Model | Continuous | ||||||||
| Specification | Power Supply | 100～120V or 200～240V, 50/60Hz | 200～240V, 50/60Hz | |||||||
| Sizes(W×D×H)(mm) | 320x160 x170 | 360x180 x180 | 420x210 x200 | 610x160 x170 | 690x180 x180 | 810x210 x200 | 940x160 x170 | 1060x180 x180 | 1240x210 x200 | |
| Shipping Size (W×D×H)(mm) | 360x19 0x200 | 400x220 x210 | 570x180 x190 | 650x190 x200 | 730x220 x210 | 850x250 x230 | 980x190 x200 | 1100x220 x210 | 1280x250 x230 | |
| N.W./G.W. (kg) | 4/5 | 4/5 | 7/8 | 8/10 | 8/10 | 14/16 | 12/15 | 12/15 | 21/24 | |
Magnetic Stirring Heating Mantles Feature:
Efficient Surface Heat Conduction: The use of surface heat conduction technology in Magnetic Stirring Heating Mantles ensures efficient and uniform heating of the reaction vessel. This feature promotes consistent and controlled temperature conditions for various laboratory processes.
High Maximum Surface Temperature: With a surface max temperature of 450℃, these mantles provide a broad temperature range suitable for a variety of applications, including high-temperature reactions and processes.
Wide Temperature Control Range: Offering a temperature control range from RT (Room Temperature) +20 to 250℃, Magnetic Stirring Heating Mantles provide flexibility in accommodating a diverse range of experimental requirements.
Versatile Speed Control: The mantles feature a wide speed range from 0 to 1600rpm, allowing for precise control over the stirring speed. This versatility makes them suitable for applications with varying viscosities and mixing requirements.
Durable Heating Element: Constructed with a heating element made of nickel-chromium alloy wire, these mantles ensure durability and reliability in heating applications. The alloy's properties contribute to stable and efficient heating performance.
