JL269 Serials Gas Leakage Detector

Model:

JL269-E: LED Indicate

JL269-C: LCD Display

Features:

1. Calibration-free on gas sensor

2. Quick response to combustible gas leakage

3. Long and flexible gooseneck tube

4. Adjustable sensitivity

5. 30-level LED / tricolor show

6. Battery low voltage alert

7. Sensor fault self test

Specifications:

1. Detecting Gas: Natural gas, LPG

2. Sensitivity: better than 50ppm

3. Detection range: 0ppm-30000ppm, 0~60%LEL, 0-3.0%VOL

4. Working condition: Temperature. -40ºC-70ºC Humidity: <=95% RH

5. Warm-up time: <20S

6. Response time: <10S

7. Indication: 30 levels of LED indication

8. Green: low concentration

9. Yellow: middle concentration

10. Red: high concentration

11. Alarming levels: The shorter the frequent buzzer sound, the higher the concentration reach

12. Power supply: Ni-H chargeable battery DC3.6V 1600mAh

13. Charge time: 4-6 hours

14. Using time of the battery: >8h

15. Weight: about 310g

16. Dimensions: 170 x 62 x 26mm
