FM-204-500K Digital Force Gauge

Features:

1. High accuracy and high resolution.

2. Digital display with no guessing or errors.

3. With 4 measurement unit for selection and conversion, N, kg, lb, g.

4. With peak value hold function.

5. With 10 minutes auto power off and manual power off.

6. Power can be supplied by either alkaline battery or 5V DC power.

Specifications:

1. Force Range: ±500kgf; ±4900N; ±1100Lbf

2. Resolution: 0.01kgf (<100kgf); 0.1kgf (≥100kgf); 0.01N (<1000N); 1N (≥1000N); 0.1Lbf (<1000Lbf); 1Lbf (≥1000Lbf)

3. Accuracy: ±0.5%FS ±1Digit

4. Unit: kgf, gf, N, Lbf

5. Measurement State: Peak Value Measurement, Real Time Measurement

6. Display: 2 Reversed 4 Digit LCD

7. Power Off: 10 Minutes Auto Power Off, Manual Power Off

8. Backlight: Blue Backlight

9. Safe Load: 150%FS (Buzzer Alarm Over 110%FS)

10. Power Supply: 2x1.5 AA (UM-3) Battery or 6V DC Power Supply

11. Operating: Temperature: 0~40ºC

12. Conditions: Humidity: <80%

13. Surrounding: No Vibration Source or Corrosive Medium Around

14. Weight: 1165g

15. Case Size: 175x80x36mm

16. Senor Size: 181x54x30mm
