Dry Bath with Heating & Cooling & Mixing (scitek-0930) Products
| Name | Dry Bath with Heating & Cooling & Mixing |
| Code | scitek-0930 |
| Type | Standard |
| Brand | Scitek |
| Category | PCR Analyzer and Pretreatment |
| subcategory | Dry Block Incubators |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Product details for Invoice
Model : DB-HCM100; DB-HM100; DB-H100
Display : TFT
Temperature Control Accuracy : ±0.5℃ (At 20~45℃)
Temperature Setting Range(℃) : 0.1~100; 15~100; 15~100
Max. Heating Rate : 5.5℃/min
Size(W×D×H)(mm) : 200×235×120
The dry bath with heating & cooling & mixing function increases the versatility of the laboratory.
Display : TFT
Temperature Control Accuracy : ±0.5℃ (At 20~45℃)
Temperature Setting Range(℃) : 0.1~100; 15~100; 15~100
Max. Heating Rate : 5.5℃/min
Size(W×D×H)(mm) : 200×235×120
The dry bath with heating & cooling & mixing function increases the versatility of the laboratory.
Product Details
Dry Bath Specifications:
| Model | DB-HCM100 | DB-HM100 | DB-H100 |
|---|---|---|---|
| Functions | Heating, Cooling & Mixing | Heating & Mixing | Heating |
| Temperature Range | Heating: RT.~100℃ | Heating: RT.~100℃ | Heating: RT.+5-100℃ |
| Cooling: RT.~below RT. 15℃ | |||
| Temperature Setting Range(℃) | 0.1~100 | 15~100 | 15~100 |
| Temperature Control Accuracy | ±0.5℃ (At 20~45℃) | ±0.5℃ (At 20~45℃) | ±0.5℃ |
| Temperature Uniformity | ±0.5℃ (At 20-45℃) | ±0.5℃ (At 20-45℃) | ±0.5℃ (At37℃) |
| Max. Heating Rate | 5.5℃/min | ||
| Max. Cooling Rate | 5℃/min (RT.~100℃) | – | |
| 0.5℃/min (Below RT.) | |||
| Mixing Frequency | 200rpm-1500rpm | 200rpm-1500rpm | |
| Mixing Orbit | 3 mm | 3 mm | |
| Time Setting Range | 0~99h30min | ||
| Program | 9 | 9 | 6 Sequential steps |
| Overheating Protection | 150℃ | ||
| Display | TFT | ||
| Adapter Block Material | Aluminum | Aluminum | Aluminum |
| Poer Supply | AC220/110V, 50/60Hz | AC100V-240V, 50Hz/60Hz | |
| Consumption | 200W | ||
| Size(W×D×H)(mm) | 200×235×120 | ||
| Shipping Size(W×D×H)(mm) | 440x410x270 | 450x410x280 | 440x410x270 |
| N.W./G.W. (kg) | 7/8 | 5.5/7 | 7/8 |
Dry Bath Feature:
Dry bath provides more precise temperature control and faster heating and cooling rates.
Programmable features allow for automatic temperature and time control according to the experiment's needs. This improves the efficiency and accuracy of experiments and reduces errors.
Flexible adapters are compatible with a wide range of tubes, reducing equipment costs.
Quick block exchange using magnet adhesion technology allows for easy replacement of heating blocks, increasing the convenience and efficiency of experiments.
Blocks are fitted with lids to protect samples from external contamination and prevent heat loss for better insulation.
