| Name | Constant Temperature Incubator |
| Code | biobase-0230 |
| Type | Standard |
| Brand | Biobase |
| Category | Laboratory Incubator |
| subcategory | Constant-Temperature Incubator |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
Features:
* Unique vertical double duct supply horizontal air circularly.
* 4 grades 3 speed adjustable speed fan, LED running indicator light.
* Over-temperature protection system: LED red light on meanwhile cut off heating circuit to improve product safety when workroom temperature exceed the alarm value.
* High precision digital independent temperature limiter.
* 304:SUS304 Stainless Steel Body.
Technical Parameters:
Model | BJPX-H30BE | BJPX-H45BE | BJPX-H65BE | BJPX-H85BE | BJPX-H125BE | BJPX-H230BE |
Cycle Mode | Forced convection | |||||
Temp. Range | ||||||
Temp. Resolution | 0.1℃ | |||||
Temp. Fluctuation | ±1℃ | |||||
Temp. Uniformity | ±1.0℃ | |||||
Volume | 30L | 45L | 65L | 85L | 125L | 230L |
Shelf Number | 5 | 6 | 8 | 8 | 11 | 17 |
Load Per Rack | 15kg | |||||
Shelf Space | 40mm | |||||
Inner Chamber | Mirror Stainless Steel | |||||
Outer Shell | Cold rolling steel electrostatic spraying exterior | |||||
Insulation Layer | High quality foam board | |||||
Heater | Stainless steel electric heating tube | |||||
Exhaust Hole | ∅35mm top( with function of test hole) | |||||
Temp. Control Mode | Two temperature section intelligent PID | |||||
Temp. Setting Mode | Touch button setting | |||||
Temp. Display Mode | Measuring temperature: LCD upper screen; setting temperature: LCD lower row | |||||
Timer | 0~9999min(with timing wait function) | |||||
Operation Function | Fixed temperature operation, fixed timing function, auto stop. | |||||
Additional Function | Digital Independent temp. limiter. 4grades 3 speed adjustable speed fan(230 without fan speed adjust) Sensor deviation correction, temperature overshoot self-tuning, internal parameter locking, power-off parameter memory | |||||
Sensor | PT100 | |||||
Safety Device | Over temp.sound-light alarm, Digital Independent temp. limiter | |||||
Optional Accessories | Shelf, U-disk storage, Printer, 3.5-inch color touch screen temperature controller. | |||||
Power Supply | 220V/1.8A | 220V/2.3A | 220V/3.2A | 220V/4.1A | 22V/5A | 220V/6.8A |
Power | 0.4kW | 0.5kW | 0.7kW | 0.9kW | 1.1kW | 1.5kW |
Internal Size(W*L*H)mm | 310*310*310 | 350*350*350 | 400*360*450 | 450*420*450 | 500*450*550 | 600*500*750 |
460*510*695 | 500*550*735 | 550*550*840 | 590*610*830 | 636*680*915 | 735*835*1115 | |
Package Size(W*L*H)mm | 540*575*855 | 580*615*895 | 635*625*995 | 680*685*1000 | 710*730*1100 | 857*885*1287 |
NW/GW(kg) | 33/37 | 37/43 | 44/49 | 50/56 | 60/66 | 94/120 |
