Objective

4X, 10X, 40X(spring)

√

√

√

Eyepiece

Wide field eyepieces WF10X(WF25X or WF20X, WF16X or H16X optional)

√

√

√

Viewing Head

Monocular

√

√

√

Nosepiece

Triple

√

√

√

Stage

Plain stage with paired clips

√

√

√

Plain stage with moving scale

●

/

●

Focusing

Coarse adjustment focusing

√

√

√

Coaxial coarse and fine adjustment focusing

/

/

/

Illumination&Condenser

Rotating disc diaphragm

√

/

√

N.A=0.65 abbe condenser&rotating disc diaphragm

/

√

/

Flat concave reflector

/

/

/

Electric light source top LED    (incandescent optional)

/

/

/

Electric light source bottom LED(incandescent optional)

/

/

/

Electric light source top and bottom LED(incandescent optional)

√

√

√

Power

Power: battery

√

√

√

AC Input 100~230V, DC output 5V

/

√

√

Package Size(mm)

160*220*300

160*220*300

160*220*300

Gross Weight(kg)

1.8

2.5

2

Objectives

Achromatic Objectives: 4X, 10X, 40X(S), 100X(S, Oil)

√

√

Plan Objectives: 4X, 10X, 40X(S), 100X(S, Oil)

●

●

Infinite Achromatic Objectives: 4X, 10X, 40X(S), 100X(S, Oil)

●

●

Infinite Plan Objectives: 4X, 10X, 40X(S), 100X(S, Oil)

●

●

Eyepiece

Wide Field Eyepiece: WF10X(18mm), (WF16X  optional)

√

√

Viewing Head

Compensation Free Binocular Head, Inclined at 30°
