| Name | BIOBASE MX-S MX-F Mini Vortex Mixer Shaker Lab |
| Code | biobase-0571 |
| Type | Standard |
| Brand | Biobase |
| Category | Liquid Processing Instruments |
| subcategory | Mixer |
| Unit | pcs (pcs) |
| In Stock | Yes |
| Berminat hub kami: |  |
The Vortex Mixer is a versatile and essential laboratory instrument designed for rapidly mixing small vials of liquids. It is ideal for use in research laboratories, clinical settings, pharmaceutical labs, and educational institutions where efficient and consistent mixing of samples is required.
Features
1. Touch operation or continuous mode.
2. Variable speed control from 0 to 2500rpm (MX-S).
3. Fixed Speed 2500rpm (MX-F).
4. Used for various mixing applications with optional adapters (MX-S).
5. Specially designed vacuum suction feet for body stablility.
6. Robust aluminum-east construction.
7. When the test tube adapter or flat gasket accessory is selected, it must be matched with VY1.2 or VT1.3.
Technical Parameters:
Model | MX-S | MX-F |
ltem No. | 8031102000 | 8031101000 |
Shaking Mode | Orbital | |
Orbital Diameter | 4mm | |
Motor Type | Shaded pole motor | |
Motor Input | 58W | |
Motor Output | 10W | |
Speed Range | 0~3000rpm | 3000rpm |
Speed Display | Scale | / |
Operation Mode | Continuous/touch operation | |
Ambient Temp. | 5~40℃ | |
Relative Humidity | 80% | |
Protection Type | IP21 | |
Power Consumption | 60W | |
Power Supply | AC110/220V±10%, 50/60Hz (Customizable) | |
Standard Accessories | VT1.1 standard top | |
External Size(W*D*H) | 127*130*160mm | |
Package Size(W*D*H) | 300*250*230mm | |
Gross Weight | 3kg | |
Accessories | MX-S (0~2500rpm) | |
Touch Mode | Continuous Mode | |
VT1.1 | Standard | Standard |
| Optional | / |
VT1.2+VT1.3.2 | Optional | / |
VT1.2+VT1.3.3 | Optional | / |
VT1.2+VT1.3.4 | Optional | / |
VT1.2+VT1.3.5 | Optional | / |
VT1.3+VT1.3.6 | Optional | |
VT1.3+VT1.3.1 | / | Optional |
VT1.3+VT1.3.2 | / | Optional |
VT1.3+VT1.3.3 | / | Optional |
VT1.3+VT1.3.4 | / | Optional |
VT1.3+VT1.3.5 | / | Optional |
Application of accessories:
Cat.No. | P/N |
18900044 | VT1.2 |
18900505 | VT1.3+VT1.3.7 |
18900020 | VT1.3.1 |
18900021 | VT1.3.2 |
18900395 | VT1.3.8 |
18900022 | VT1.3.3 |
18900023 | VT1.3.4 |
18900024 | VT1.3.5 |
18900043 | VT1.3.6 |
18900158 | VT1.3.7 |
