tlead-1495 - AMF018H Ultrasonic Thickness Gauge

AMF018H Ultrasonic Thickness Gauge (tlead-1495) Products

Name	AMF018H Ultrasonic Thickness Gauge
Code	tlead-1495
Type	Standard
Brand	Amtast
Category	Test Instruments
subcategory	Thickness Meter -Ultrasonic
Unit	pcs (pcs)
In Stock	Yes
Berminat hub kami:

Product details for Invoice

Ultrasonic Thickness Gauge AMF018H *Measuring range: 1.0~300mm (Steel) *Accuracy: (1%H+0.1) mm *Resolution: 0.01mm *Sound velocity range: 1000~9999m/s *Working frequency: 5MHz *Minimum limit for tube measuring: 10mm probe: 20*3mm (Steel); 6m

Product Details

Ultrasonic Thickness Gauge AMF018H

*Measuring range: 1.0~300mm (Steel)

*Accuracy: ±(1%H+0.1) mm

*Resolution: 0.01mm

*Sound velocity range: 1000~9999m/s

*Working frequency: 5MHz

*Minimum limit for tube measuring: Φ10mm probe: Φ20*3mm (Steel); Φ6mm probe: Φ12*2mm (Steel)

*Auto calibration to assure the accuracy

*Auto linear compensation: this advanced software program enhances the precision by correcting the non-linear accuracy of transducer.

*Data store/ Data recall/ Data delete function

*Sound velocity measurement
