A005-5 Conductivity Meter

Features:

1. Design of board card modularity, for convenience of assembly and configuration.

2. 2.4 inches 12864 lattice screen.

3. Isolating transmitting output, with little interference.

4. Isolating RS485 communication.

5. EC/TDS measurement, temperature measurement,top/bottom limit control,transmitting output, RS485 communication.

6. Configurable manual and auto temperature offset function.

7. Configurable upper/lower limit warning and delay.

8. Configurable hummer and LCD backlight switch.

9. Addition of universal password.

10. Industrial controlled door keep, to avoid instrument halted.

Specifications:

1. Configurable isolating transmitting 4-20mA output,max.loop750Ω, 0.1%FS.

2. Measuring range: (Sensor optional, when order please inform sensor model, standard length 5m, can supply max 20m, optional)

    1) 0.01 electrode: 0.02~20.00us/cm; material: SS316L

    2) 0.1 electrode: 0.2~200.0us/cm; material: SS316L

    3) 1.0 electrode: 2~2000us/cm; material: SS316L

    4) 10.0 electrode: 20~20000us/cm; material: PSU

3. Accuracy: ±1%FS

4. Stability: ±1%FS/24H

5. Temperature measuring range: -10~130°C, accuracy: ±0.5°C, NTC10K or PT1000 temperature offset

6. Temperature compensation:-10~130°C manual/auto

7. RS485 function: compactible with standard MODBUS-RTU communication protocol

8. Supply power: AC220V±10%,50Hz/60Hz

9. Warning relay: AC250V, 3A
